ویژگی دوربین مداربسته CNB IGC-2050F :
– 2.0 Mega-Pixel Resolution up to 30 Frames/sec
– Ultimate High Resolution 1100TV Lines
– Built-in System State LED/MIC
– Dual Stream H.264/MJPEG
– Support Two-way Audio (ADPCM)
– Support SD Card Local Storage for Event
– Ethernet 10/100 Base-T (PoE)
مشخصات فنی دوربین مدار بسته CNB IGC-2050F :
| Model | IGC2050F |
| ..[Camera] | |
| Image Sensor | 1/3″ Progerssive CMOS Sensor |
| Scaning System | 16:9 Progressive |
| Sync. System | Internal |
| Effective Pixels Number | 1920(H) x 1080(V) 2.0 Mega |
| Horizontal Resolution | 1100 TV Lines |
| Video Output Level | Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite) |
| Lens Mount | CS Mount |
| Day & Night System | ICR (CDS Type) |
| Min. Illumination | 1Lux (Color, DSS On), 0.05Lux (B/W, DSS On) |
| Flickerless | On/Off |
| White Balance | Auto/Manual |
| Exposure | Auto/Manual |
| Function | BLC, Color, B/W |
| Elec. Shutter Speed | NTSC : 1/7.5~1/8,000 (21 Step) PAL : 1/7.5~1/8,000 (21 Step) |
| ..[Video / Audio] | |
| Compression | H.264 / MJPEG |
| Resolution | Full HD, SXGA, 720P, XGA, D1, VGA, CIF, QVGA |
| Audio | Two-way (full duplex / ADPCM G.711) |
| ..[Network] | |
| Protocol | IPv4, HTTP, TCP, RTSP, RTP, RTCP, UDP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour, ARP, DNS, DynDNS |
| Supported DDNS | Supported (CNB DDNS) |
| LAN Interface | Ehternet 10/100 Base-T (RJ-45 Type) |
| ..[Security] | |
| Access Level Setup | Multiple user access levels with password protection |
| Network Security | IP Filtering |
| ..[Alarm and Event Managerment] | |
| Image Detection | Motion detection (Select 3 Regions – each area) |
| Sensor Detection | Sensor In, Scheduling, Alarm out |
| Local Storage | SD/SDHC Card Memory : Max. 32GByte (Class 4 or Higher) |
| After Event process | JPEG Image upload over FTP server JPEG Image or Notification Message Upload over SMTP (E-mail server) |
| Pre/Post alarm | Detail time-set : Max. Pre alarm 5sec. Post alarm 8sec., Storage (SD card : JPEG Image, H.264 Movie file) |
| ..[Applications] | |
| Browser | Internet Explorer 6.0 or higher |
| Monitoring Application | XNET NVR 2, and Utility (IP-Installer) |
| ..[Maintenance] | |
| System Upgrade | Firmware upgrade over HTTP |
| ..[Mechanical] | |
| PoE | Standard IEEE 802.3af supported |
| Power | DC 12V Max. 4W |
| Dimensions | 71(W) x 65(H) x 143.9(D)mm |
| Weight(Net) | Approx. 417.5g |
