| Camera |
| Image Sensor: |
1/4″ progressive scan CMOS |
| Signal System: |
PAL/NTSC |
| Min. Illumination: |
0.01Lux @(F1.2,AGC ON) ,0 Lux with IR
0.028Lux @(F2.0,AGC ON) ,0 Lux with IR |
| Shutter time: |
1/3 s to 1/100,000 s |
| Lens: |
4mm@ F2.0, Angle of view: 59° (2.8mm, 6mm optioanl) |
| Lens Mount: |
M12 |
| Adjustment Range: |
Pan:0° – 355°, Tilt: -20° – 90° |
| Day& Night: |
IR cut filter with auto switch |
| Wide Dynamic Range: |
Digital WDR |
| Digital noise reduction: |
3D DNR |
|
| Compression Standard |
| Video Compression: |
H.264/M-JPEG |
| Bit Rate: |
32 Kbps~8Mbps |
| Audio Compression: |
G.711/G.726/MP2L2 |
| Dual Stream: |
Yes |
|
| Image |
| Max. Image Resolution: |
1280×720 |
| Frame Rate: |
50 Hz: 25 fps (1280 × 720), 25 fps (704 × 576), 25 fps (640 × 480)
60 Hz: 30 fps (1280 × 720), 30 fps (704 × 576), 30 fps (640 × 480) |
| Image Settings: |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC: |
Yes, zone configurable |
| ROI: |
Support |
|
| Network |
| Network Storage: |
NAS |
| Alarm Trigger: |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Security: |
User Authentication, Watermark, IP address filtering, anonymous access |
| System Compatibility: |
ONVIF, PSIA, CGI, ISAPI |
|
| Interface |
| Audio Input: |
1 built-in microphone |
| Audio Output: |
1-ch 3.5 mm audio interface, 1 built-in speaker |
| Communication Interface: |
1 RJ45 10M / 100M ethernet interface |
| Alarm Input: |
1 |
| Alarm Output: |
1 |
| On-board storage: |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
Yes |
|
| Wi-Fi Specification (-W) |
| Wireless Standards: |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range: |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth: |
20/40MHz Support |
| Modulation Mode: |
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM |
| Security: |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
|
|
